Fix YOLO26 ONNX opset 18 TensorRT 8.5 Concat Shape Mismatch on node_cat_25

Fix YOLO26 ONNX opset 18 TensorRT 8.5 Concat Shape Mismatch on node_cat_25

When you export YOLO26 to ONNX opset 18 and build a .engine with TensorRT 8.5.2, trtexec or the TensorRT parser may stop on a Concat node and print a shape conflict like this:

[E] [TRT] ModelImporter.cpp:728: input: "slice_2"
input: "getitem_62"
input: "_to_copy"
output: "output"
name: "node_cat_25"
op_type: "Concat"
attribute {
  name: "axis"
  i: -1
  type: INT
}

The short answer: TensorRT 8.5.2 is mis-inferring the output shapes of ReduceMax / ArgMax nodes in your detection-head post-processing. Rewrite the export wrapper to avoid those ops — use direct tensor assignment for single-class models and torch.topk for multi-class — then re-export ONNX.

When this shows up

You are likely hitting this if:

• PyTorch inference works, but trtexec --onnx=model.onnx fails during ONNX import
• The failing node is a Concat near the model output, often named node_cat_*
• TensorRT logs show one input as [-1, 8400, 4] and the others as [1, 1, 1]
• You exported with opset 18 and are building on TensorRT 8.5.x (released before opset 18)
• The model is a YOLO-style detector with a custom DeepStreamOutput or similar post-processing head

Common stack:

• Ultralytics YOLO26 (or YOLOv8/v11 family) custom export script
• PyTorch 2.x torch.onnx.export or Dynamo exporter
• TensorRT 8.5.2 on Ubuntu 20.04/22.04 with CUDA 11.x
• Deployment targets: DeepStream, Triton, or standalone trtexec

Environment and versions

Component	Example version
Model	YOLO26 detection head, 640×640 input
ONNX opset	18
TensorRT	8.5.2
Candidate count	8400 (= 80² + 40² + 20²)

TensorRT 8.5 predates ONNX opset 18. Opset 18 changed how several reduction ops represent their axes argument — from a node attribute to a second input tensor. That difference matters when TensorRT walks the graph and infers intermediate shapes.

What the export code is trying to do

A typical YOLO26 DeepStream export wrapper transposes the detection head output, splits boxes from class scores, reduces over the class dimension, and concatenates:

def forward(self, x):
    x = x.transpose(1, 2)                          # [B, 4+C, 8400] → [B, 8400, 4+C]
    boxes = x[:, :, :4]                            # [B, 8400, 4]
    scores, labels = torch.max(x[:, :, 4:], dim=-1, keepdim=True)  # [B, 8400, 1] each
    return torch.cat([boxes, scores, labels.to(boxes.dtype)], dim=-1)  # [B, 8400, 6]

For a single-class model (C=1), the detection head feeds [B, 5, 8400]. After transpose:

boxes        = [B, 8400, 4]
class_scores = [B, 8400, 1]
scores       = [B, 8400, 1]   # ReduceMax over axis=-1, keepdims=1
labels       = [B, 8400, 1]   # ArgMax over axis=-1, keepdims=1
output       = [B, 8400, 6]   # [x1, y1, x2, y2, confidence, class_id]

ONNX represents torch.max(..., dim=-1, keepdim=True) as roughly:

scores ← ReduceMax(class_scores, axes=[-1], keepdims=1)
labels ← ArgMax(class_scores, axes=[-1], keepdims=1)

With keepdims=1, the reduced class dimension stays at size 1. The 8400 candidate dimension must survive untouched.

Why TensorRT reports [1, 1, 1]

During engine build, TensorRT shape inference may log:

Input 0 shape: [-1, 8400, 4]    # boxes — correct
Input 1 shape: [1, 1, 1]        # scores — wrong
Input 2 shape: [1, 1, 1]        # labels — wrong

Concat along axis=-1 (axis 2) requires all non-concat dimensions to match. Batch -1 vs 1 can work in dynamic-batch mode, but 8400 vs 1 on dimension 1 is a hard failure — that is what triggers the node_cat_25 error.

The [1, 1, 1] shape is not what your PyTorch code intends. It is what TensorRT 8.5.2 infers after parsing the ONNX graph. The error lives in the ONNX-to-TensorRT shape-resolution chain, not necessarily in the ONNX file’s stored value_info (see the diagnostic step below).

opset 13 vs opset 18: why axes matter

In opset 13, ReduceMax carries axes as a node attribute:

ReduceMax(data, axes=[-1], keepdims=1)

In opset 18, axes becomes a second input tensor:

axes = Constant([-1])
ReduceMax(data, axes, keepdims=1)

TensorRT 8.5.2 was not built for this pattern. Combined with dynamic batch, keepdims, a follow-up Expand (from labels.to(dtype).expand_as(scores)), and the final Concat, the parser can collapse the 8400 dimension and produce [1, 1, 1].

The third Concat input _to_copy is the dtype cast labels.to(boxes.dtype). An Expand node may also appear (Expand_output_0) when the exporter tries to broadcast labels to match scores — but if scores are already wrong at [1, 1, 1], Expand propagates the bad shape instead of fixing it.

Confirm where the shape breaks

Run ONNX shape inference on the exported model before blaming TensorRT alone:

python3 - <<'PY'
import onnx
from onnx import shape_inference

path = "best.onnx"  # your exported model
model = shape_inference.infer_shapes(onnx.load(path))

shapes = {}
for value in list(model.graph.value_info) + list(model.graph.output):
    dims = []
    for d in value.type.tensor_type.shape.dim:
        dims.append(d.dim_param or d.dim_value or "?")
    shapes[value.name] = dims

for node in model.graph.node:
    if node.op_type in {"Slice", "ReduceMax", "ArgMax", "Expand", "Concat"}:
        print(f"\n{node.op_type}: {node.name}")
        for name in node.input:
            print(" input :", name, shapes.get(name, "<unknown>"))
        for name in node.output:
            print(" output:", name, shapes.get(name, "<unknown>"))
PY

How to read the output:

ONNX inference	TensorRT build	Likely cause
[batch, 8400, 1]	[1, 1, 1]	TensorRT 8.5 parser incompatibility with opset 18 reduction ops
[1, 1, 1]	[1, 1, 1]	Shape already wrong in the exported ONNX graph
ONNX Runtime outputs [B, 8400, 6] for batch 1 and 16	TensorRT fails	Model semantics are fine; TensorRT parsing is the problem

Fix: rewrite the export post-processing

Avoid torch.max (and therefore ReduceMax / ArgMax / Expand) in the ONNX export path.

Single-class models

When C=1, max and argmax are redundant — the only class score is already the confidence, and the label is always 0:

def forward(self, x):
    x = x.transpose(1, 2)
    boxes = x[:, :, :4]
    class_scores = x[:, :, 4:]          # [B, 8400, 1]

    scores = class_scores              # Identity — no ReduceMax
    labels = class_scores * 0.0        # Mul by zero → float 0.0, keeps [B, 8400, 1]

    return torch.cat([boxes, scores, labels], dim=-1)

This removes ReduceMax, ArgMax, and Expand from the ONNX graph. TensorRT only sees Slice, Mul, and Concat — shapes stay [B, 8400, *] throughout.

Multi-class models

Use torch.topk instead of torch.max. Semantics are the same (highest class score and its index), but ONNX expresses it as TopK, which TensorRT 8.5 handles more reliably:

def forward(self, x):
    x = x.transpose(1, 2)
    boxes = x[:, :, :4]
    class_scores = x[:, :, 4:]

    scores, labels = torch.topk(class_scores, k=1, dim=-1)  # [B, 8400, 1] each
    labels = labels.to(boxes.dtype)

    return torch.cat([boxes, scores, labels], dim=-1)

Re-export and build the engine

Wire the updated forward into your existing export script and re-run torch.onnx.export, keeping opset 18 if your runtime requires it:

import torch

dummy_input = torch.zeros(1, 3, 640, 640)
torch.onnx.export(
    model_with_updated_forward,  # wrapper with the fix above
    dummy_input,
    "best.onnx",
    opset_version=18,
    input_names=["images"],
    output_names=["output"],
    dynamic_axes={"images": {0: "batch"}, "output": {0: "batch"}},
)

Verify with ONNX Runtime first:

python3 -c "
import onnxruntime as ort
import numpy as np
sess = ort.InferenceSession('best.onnx')
out = sess.run(None, {sess.get_inputs()[0].name: np.zeros((1,3,640,640), np.float32)})[0]
print('output shape:', out.shape)  # expect (1, 8400, 6)
"

Then build with TensorRT:

trtexec --onnx=best.onnx --saveEngine=best.engine --fp16

If import succeeds, the node_cat_25 Concat error is resolved.

Alternative approaches

These also work but change your constraints:

• Lower the ONNX opset to 13 or 17 so axes stays an attribute. Test whether TensorRT 8.5.2 parses the graph correctly at the lower opset.
• Upgrade TensorRT to 8.6+ or TensorRT 10.x, which ship better opset 18 support.
• Export without post-processing and run max/argmax/concat in CPU/GPU code outside the engine (common in DeepStream custom parsers).

Downgrading opset or upgrading TensorRT is often easier in greenfield projects. Rewriting the export wrapper is the better fix when you are pinned to TensorRT 8.5.2 and opset 18.

FAQ

What does the TensorRT error on node_cat_25 actually mean?

TensorRT found a Concat node whose inputs have incompatible shapes on a non-concat axis. Here, boxes is [-1, 8400, 4] but scores and labels were inferred as [1, 1, 1], so dimension 1 cannot be reconciled (8400 ≠ 1).

Is [1, 1, 1] the real ONNX output shape?

Not necessarily. It is the shape TensorRT 8.5.2 infers during engine build. The ONNX file may still describe [batch, 8400, 1] in its shape metadata. Run the ONNX shape-inference script above to see what the ONNX toolchain itself believes.

Why does PyTorch inference work but TensorRT fails?

PyTorch executes the graph operationally — it never needs to statically infer every intermediate shape at compile time. TensorRT must resolve all shapes (or dynamic-shape ranges) before fusion and kernel selection. A shape-parser bug or opset mismatch only appears at engine-build time.

Does lowering batch size to 1 fix this?

No. The failure is on the 8400 candidate dimension, not batch. Even with batch=1, scores should be [1, 8400, 1], not [1, 1, 1].

Can I keep torch.max if I use opset 13?

Sometimes. Opset 13 keeps axes as an attribute, which TensorRT 8.5 handles more predictably. If you must stay on opset 18, rewrite the post-processing as described above.

What is the _to_copy input in the error log?

It is the ONNX name for labels.to(boxes.dtype) — casting integer class indices to float32 so they can sit in the same tensor as box coordinates and confidence scores.
